Cleanroom Light Fitting 6013
Art. No.:
309613
Product Type:
6013/5221-2500-0123-0111
min. ambient temperature:
-20 °C
Lamp wattage:
28 W
max. ambient temperature:
+45 °C
Frequency range:
50 - 60 Hz
AC rated operational voltage:
220 - 240 V
Zone Filter:
Zone 1 | 2 G | Gb / Zone 2 | 3 G | Gc
Certificates:
IECEx (IBE)
Lamp:
LED
Light colour:
Cool white
Enclosure material:
Stainless steel 1.4301
Max. solid connection terminals:
4 mm²
Type of connection cable:
Finely stranded with clip, solid
Drilled holes:
3 x M20
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 6013B |
| Product Type | 6013/5221-2500-0123-0111 |
| Highlights |
Premium 304 stainless steel with brushed finish for durability Higher efficacy, at around 120 lm/W, means more light with less power Temperature range -20 °C to + 45 °C Degree of protection IP 66 Dual bottom and top openings provide easy access to input field terminals Adjustable ceiling brackets for precise mounting based on the ceiling depth IECEx certified Cleanroom compliance luminaire |
| Functional Description | The 6013 series is an ideal lighting solution tailored for cleanroom applications. Highlighting its versatility, this innovative series is equipped with adjustable built-in C brackets for recessed mounting providing unmatched flexibility and allowing for seamless installation and operation from both the top and bottom of the ceiling. The luminaire's user-friendly design, coupled with its lightweight construction, not only optimizes ceiling grid load capacity but also guarantees efficiency without any compromise. |
