Auxiliary contactor Series 8510
Art. No.:
145751
Product Type:
8510/141-03-606-210
Product description:
Auxiliary contactor
min. ambient temperature:
-20 °C
max. ambient temperature:
+60 °C
Zone Filter:
M2 | Mb / Zone 1 | 2 G | Gb / Zone 2 | 3 G | Gc
Certificates:
ATEX (BVS), Brazil (ULB), Canada (FM), China (CQST), IECEx (BVS), USA (FM)
Rated actuating voltage:
24 V DC
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 8510M |
| Product Type | 8510/141-03-606-210 |
| Highlights | Type-tested standard components with up to seven contactsRobust: Vibration-proof components in the corrosion-resistant enclosureEasily accessible terminals for a safe connection and simple installation |
| Functional Description | R. STAHL Series 8510 auxiliary contacts are fitted with up to seven contacts. They are screwed into the enclosure so that they are protected against vibrations. They are also low-maintenance and reliable. Easily accessible terminals make installation simple and safe. Their enclosure is made of corrosion-resistant material. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Auxiliary contactor - 8510/141-03-606-210 - 145751 - de-DE | Single Data Sheet |
 |
|
| Auxiliary contactor - 8510/141-03-606-210 - 145751 - en-GB | Single Data Sheet |
 |
|
| Auxiliary contactor - 8510 - de-DE | Product Overview |
|
|
| Auxiliary contactor - 8510 - fr-FR | Product Overview |
 |
|
| Auxiliary contactor - 8510 - es-ES | Product Overview |
 |
|
| Auxiliary contactor - 8510/141-03-606-210 - 145751 - fr-FR | Single Data Sheet |
|
|
| Auxiliary contactor - 8510/141-03-606-210 - 145751 - es-ES | Single Data Sheet |
|
