Miniature circuit breakers IEC Series 8562
Art. No.:
149761
Product Type:
8562/54-4040-320
Product description:
Miniature circuit breaker
min. ambient temperature:
-20 °C
max. ambient temperature:
+60 °C
AC rated operational voltage:
400 - 400 V
Rated operational current:
32 A
Rated switching capacity:
10 kA
Zone Filter:
M2 | Mb / Zone 1 | 2 G | Gb / Zone 2 | 3 G | Gc
Certificates:
ATEX (PTB), Brazil (ULB), China (CQST), IECEx (PTB)
N-pole present:
Yes
Tripping characteristic:
C
No. of poles:
4
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 8562B |
| Product Type | 8562/54-4040-320 |
| Product description | Miniature circuit breaker |
| Highlights | Non-adjustable thermal and magnetic releasesIsolating function in accordance with EN 60947-2Energy limiting class 3 |
| Functional Description | R. STAHL Series 8562 miniature circuit breakers boast good current limiting for short circuits and a high switching capacity of 6 or 10 kA. This results in a low load on conductors and a high selectivity for upstream fuses. The components have a modular design and are therefore available in 1- to 4-pole versions and for nominal currents from 0.5 to 40 A. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Miniature circuit breaker - 8562/54-4040-320 - 149761 - de-DE | Single Data Sheet |
 |
|
| Miniature circuit breaker - 8562/54-4040-320 - 149761 - en-GB | Single Data Sheet |
 |
|
| Miniature circuit breakers IEC - 8562 - de-DE | Product Overview |
|
|
| Miniature circuit breakers IEC - 8562 - en-GB | Product Overview |
|
|
| Miniature circuit breaker - 8562/54-4040-320 - 149761 - fr-FR | Single Data Sheet |
 |
|
| Miniature circuit breaker - 8562/54-4040-320 - 149761 - es-ES | Single Data Sheet |
 |
