Plugs 32A Series 8571/12
Art. No.:
275680
Product Type:
8571/12-504-S-XX-X-XX-XXX
Product description:
32 A plug
min. ambient temperature:
-50 °C
max. ambient temperature:
+25 °C
Rated operational current:
32 A
Certificates:
ATEX (PTB), Brazil (ULB), China (CQST), IECEx (PTB), India (PESO), Korea (KGS), Taiwan (ITRI)
Frequency range:
50 / 60 Hz
Silicone-free:
No
Colour code:
yellow
Coding (clock hour position):
4
Detailed number of poles:
3 P + N + PE
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 8571P |
| Product variant | Plug |
| Product Type | 8571/12-504-S-XX-X-XX-XXX |
| Product description | 32 A plug |
| Highlights | Different voltage ranges according to EN 60309No effect of torsional forces from the conductor on the sealLarge temperature range of useHigh mechanical impact and shock resistancePerfect protection against penetration of liquids and dusts3D data for download on the websiteVariants for use in USA/Canada available on request |
| Functional Description |
The R. STAHL 8571/12 series SolConeX plugs for Zone 1/21 are 4- or 5-pole versions up to 32 A. They can be plugged and unplugged easily and simply thanks to floating pins. The pivoting strain relief makes it easier to install the cable. Self-cleaning and corrosion-free plug pins made from high-quality materials ensure optimum electrical contact. Further product options available: - Further voltage ranges according to EN 60309 - Silicone-free versions |
| Description | 8571/12-504-S-XX-X-XX-XXX 5-pole plug, 57/100 to 75/130 V AC, 50 Hz, 32 A |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Plugs - 8571/12 - de-DE | Product Overview |
 |
|
| Plugs - 8571/12 - en-GB | Product Overview |
 |
|
| Plugs - 8571/12 - fr-FR | Product Overview |
 |
|
| Plugs - 8571/12 - es-ES | Product Overview |
 |
|
| 32 A plug - 8571/12-504-S-XX-X-XX-XXX - 275680 - de-DE | Single Data Sheet |
|
|
| Plug 32 A Plug - 8571/12-504-S-XX-X-XX-XXX - 275680 - en-GB | Single Data Sheet |
|
|
| Plug 32 A Plug - 8571/12-504-S-XX-X-XX-XXX - 275680 - fr-FR | Single Data Sheet |
|
|
| Plug 32 A Plug - 8571/12-504-S-XX-X-XX-XXX - 275680 - es-ES | Single Data Sheet |
|
