Cleanroom Light Fitting 6013
Art. No.:
313323
Product Type:
6013/5221-2500-0123-0311
min. ambient temperature:
-20 °C
Lamp wattage:
28 W
max. ambient temperature:
+45 °C
Frequency range:
50 - 60 Hz
AC rated operational voltage:
220 - 240 V
Zone Filter:
Zone 1 | 2 G | Gb / Zone 2 | 3 G | Gc
Certificates:
IECEx (IBE)
Lamp:
LED
Light colour:
Cool white
Enclosure material:
Stainless steel 1.4301
Max. solid connection terminals:
4 mm²
Type of connection cable:
Finely stranded with clip, solid
Drilled holes:
3 x M20
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 6013B |
| Product Type | 6013/5221-2500-0123-0311 |
| Highlights | Premium 304 stainless steel with brushed finish for durabilityHigher efficacy, at around 120 lm/W, means more light with less powerAmbient temperature: -20 °C to +45 °CDegree of protection IP 66Dual bottom and top openings provide easy access to input field terminalsAdjustable ceiling brackets for precise mounting based on the ceiling depthIECEx certifiedCleanroom compliance luminaire |
| Functional Description | The 6013 series is an ideal lighting solution tailored for cleanroom applications. Highlighting its versatility, this innovative series is equipped with adjustable built-in C brackets for recessed mounting providing unmatched flexibility and allowing for seamless installation and operation from both the top and bottom of the ceiling. The luminaire's user-friendly design, coupled with its lightweight construction, not only optimizes ceiling grid load capacity but also guarantees efficiency without any compromise. |
