7571/11-405, 32 A wall-mounting socket, 600 ... 690 V600 ... 690 V AC Black, 3 P + PE, 5 h, M32 x 1.5, 9 - 21 mm, Polyamide, Zone 2, 22
- Product Type: 7571/11-405
- Art. No.: 126462
Technical data
General
| MY R. STAHL | 7571A |
| Product Type | 7571/11-405 |
| Product description | 32 A wall-mounting socket |
| Highlights | For use in Zones 2 and 22, IP66 in every application positionOptional auxiliary contacts for control and signalling purposesWith AC-3 motor switching capacity according to IEC/EN 60947-3 |
| Functional Description | R. STAHL Series 7571/11 SolConeX sockets offer full AC-3 switching capacity up to 32 A for Zones 2 and 22. Self-cleaning lamellar contacts provide optimum contact and the floating pins allow the plugs to be inserted and removed in the zero position with minimum effort. The load disconnect switch, with a mechanical locking device and a handle that can be locked in the 0 or I position, is an additional safety feature. |
Explosion Protection
Electrical Data
Device Specific Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Plugs and Sockets Series 7570, 7571, 7575, 7579, 7581 | Data Sheet |
 |
|
| Plugs and Sockets Series 7570, 7571, 7575, 7579, 7581 | Data Sheet |
 |
|
| 32 A wall-mounting socket - 7571/11-405 - 126462 - de-DE | Single Data Sheet |
|
|
| 32 A wall-mounting socket - 7571/11-405 - 126462 - en-GB | Single Data Sheet |
|
|
| 32 A wall-mounting socket - 7571/11-405 - 126462 - es-ES | Single Data Sheet |
 |
|
| 32 A wall-mounting socket - 7571/11-405 - 126462 - es-ES | Single Data Sheet |
|
|
| 32 A wall-mounting socket - 7571/11-405 - 126462 - fr-FR | Single Data Sheet |
 |
