Installation switch Off switch, 690 V, Polyester resin, Number of poles: 2, Stopping plugs: 2 x M25 x 1.5, Cable glands and entries: 1 x M25 Ø 7 ... 17 mm, Sealing material: Silicone, Zone 1/2/21/22
- Product Type: 8040/11-V30-033-S
- Art. No.: 245656
Available in 6 to 10 days
Technical data
General
| MY R. STAHL | 8040F |
| Product Type | 8040/11-V30-033-S |
| Highlights | Two-pole off switch or two-way switch versionEnclosure made of glass fibre reinforced polyester resinDegree of protection IP66 according to IEC/EN 60529Clear position display 0/1 or ON/OFF |
| Functional Description | The installation switches of Series 8040/11-V30 are used for switching lighting systems. The switching position is clearly shown by the 90° switch. This is an advantage if the lighting system and the switch are housed in different rooms. The fluorescent rotary actuator makes orientation possible if the lighting fails. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
