8510/132-01-147-320, Surge arrester, 240 V, Zone 1, 2
- Product Type: 8510/132-01-147-320
- Art. No.: 210470
On request
Technical data
General
| MY R. STAHL | 8510X |
| Product Type | 8510/132-01-147-320 |
| Product description | Surge Arrester |
| Highlights | Type-tested standard componentsFor protecting low-voltage systems and switchgear from surgesCorrosion-resistant enclosure material |
| Functional Description | The R. STAHL Series 8510 surge arrester is a type-tested standard component which protects low-voltage systems and switchgear from surges. It is housed in a corrosion-resistant enclosure and can be fitted in Ex e enclosures using a screw connection so that it is protected against vibrations. Easily accessible connection terminals simplify installation. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Surge Arrester Series 8510 | Data Sheet |
 |
|
| Surge Arrester Series 8510 | Data Sheet |
 |
|
| Surge Arrester Series 8510 | Data Sheet |
 |
|
| Surge Arrester Series 8510 | Data Sheet |
 |
|
| Surge Arrester Series 8510 | Data Sheet |
 |
|
| Surge arresters - 8510 - de-DE | Product Overview |
|
|
| Surge arresters - 8510 - en-GB | Product Overview |
|
|
| Surge arresters - 8510 - es-ES | Product Overview |
|
|
| Surge arresters - 8510 - fr-FR | Product Overview |
|
|
| Surge arrester - 8510/132-01-147-320 - 210470 - de-DE | Single Data Sheet |
|
|
| Surge arrester - 8510/132-01-147-320 - 210470 - en-GB | Single Data Sheet |
|
|
| Surge arrester - 8510/132-01-147-320 - 210470 - es-ES | Single Data Sheet |
|
|
| Surge arrester - 8510/132-01-147-320 - 210470 - fr-FR | Single Data Sheet |
|
