Marine navigation lights systems

Marine Lighting & Control and monitoring system for navigation and signal lights.
ontrol and monitoring system for navigation and signal lights. Custom made text and graphics on operator panel. Separate operator panel makes installation at suitable and desired location easy. Serial communication to BAMS/CAM systems, in compliance with IEC62923

Compliance standards:
IMO Res. A.694(17), IMO Res. MSC.253(83),
DNV-GL Rules for Classification of Ships,
DNV-GL Offshore Standards, IEC EN 60947-1:2007/A1:2011/A2:2014,
IEC 60945:2002, IEC EN 63000:2018, IEC62923*

  • Available Control Modules
  • Fused output modules for 24V LED lights and 24/115/230V filament lights.
  • Fused dimmable output module 115/230V
  • Fused dual blinking output module, 115/230V
  • Digital I/O modules.

11 Series (37 Products)

TRANBERG<sup>® </sup>Relay Output Module for LED Navigation Lights Series TEF4900 R. STAHL

TRANBERG® Relay Output Module for LED Navigation Lights Series TEF4900

  • DIN rail mounting.
  • 4 or 8 output circuits.
  • 2-pole switching. Both poles fused.
  • For connection of LED navigation and signal lights. Threshold current value: 34mA.
  • Connected LED light must have built in life time control.
  • Connected LED light must be selfmonitored and if a failure arise, current must be reduced to <31mA.
  • Lamp circuits galvanic isolated from control circuit
  • Local emergency switches for control of outputs.
  • Connections for main and emergency supply to output circuits.
  • Built-in snubber network which allows termination of a wide range of communication cable, 100-250 Ohm characteristic impedance. End resistors shall not be used.
  • Current detection can be disabled on any circuit if a particular system does not require this feature.
TRANBERG<sup>® </sup>Commander<sup> </sup>Utility Operator Panel Series TEF4500 R. STAHL

TRANBERG® Commander Utility Operator Panel Series TEF4500

  • Backlit text and graphics with dimming control
  • Audible and visual alarms
  • Custom made text
TRANBERG<sup>® </sup>Commander Utility - Relay Output Module Series TEF4500 R. STAHL

TRANBERG® Commander Utility - Relay Output Module Series TEF4500

  • DIN rail mounting.
  • 24 individual potential free outputs, 1 N/O contacts.
  • Built-in snubber network which allows termination of a wide range of communication cable, 100-250 Ohm characteristic impedance. End resistors shall not be used.
  • Alarm input: 24VDC opto-isolated, and volt-free contacts.
  • Alarm reset input: 24VDC opto-isolated, and volt free contacts.
TRANBERG<sup>® </sup>Navigation Lights Controller and Monitoring System Series TEF4800 R. STAHL

TRANBERG® Navigation Lights Controller and Monitoring System Series TEF4800

  • Customer specified texts on panel.
  • The system is applicable to both LED and incandescent lamps.
  • Up to 10 pcs. 24 VDC (max. 40 W) incandescent lamps or 16 pcs. LED lamps.
  • Connections for main and emergency supply to output circuits.
  • Can be expanded with a secondary controller.
TRANBERG<sup>® </sup>Navigation Light System Operator Panel Series TEF4900 R. STAHL

TRANBERG® Navigation Light System Operator Panel Series TEF4900

  • Backlit text and graphics with dimming control
  • Audible and visual alarms
  • Main and spare lanterns in same buttons
  • Function keys which automatically turns on and off outputs
  • Custom made graphics and tex
TRANBERG<sup>® </sup>Commander Navigation Light System Central Processing Unit Series TEF4900 R. STAHL

TRANBERG® Commander Navigation Light System Central Processing Unit Series TEF4900

  • DIN rail mounting.
  • Supplies control power to the modules in the commander system.
  • Monitoring of up to 4 power supplies, 24VDC.
  • Potential free general alarm output, 1C/O contact.
  • Alarm silence digital input, 24VDC.
  • Alarm mute output, 1C/O potential-free contact. Used to mute the alarm at an external alarm centre.
  • Galvanic isolated communication port for alarm handling connection to Voyage Data Recorder (VDR) or SCADA interface.
  • Built-in snubber network which allows termination of a wide range of communication cable, 100-250 Ohm characteristic impedance. End resistors shall not be used.
TRANBERG<sup>® </sup>Commander Realy Output - Digital Input Modulet Series TEF4900 R. STAHL

TRANBERG® Commander Realy Output - Digital Input Modulet Series TEF4900

  • DIN rail mounting.
  • 4 individual potential free outputs, 1 C/O contacts.
  • 8 galvanic isolated digital inputs, 24VDC
  • Built-in snubber network which allows termination of a wide range of communication cable, 100-250 Ohm characteristic impedance. End resistors shall not be used.
TRANBERG<sup>® </sup>Fused Flasher Module with Current Detection Series TEF4900 R. STAHL

TRANBERG® Fused Flasher Module with Current Detection Series TEF4900

  • DIN rail mounting.
  • 2-pole switching. Both poles fused.
  • Zero-cross switching.
  • Build-in current detection to determine if output circuits are OK or not.
  • Lamp circuit galvanic isolated from control circuit.
  • Connections for main and emergency supply to output circuit.
  • Build-in snubber network which allows termination of a wide range of communication cable, 100-250 ohm characteristic impedance. End resistors shall not be used.
  • Current detection can be disabled if a particular system does not require this feature. This may be done in software confi guration or as a direct setting on the module.
  • The module may also be set locally to manually adjust fl ashing pattern.
TRANBERG<sup>® </sup>Fused Dimmer Module with Current Detection Series TEF4900 R. STAHL

TRANBERG® Fused Dimmer Module with Current Detection Series TEF4900

  • DIN rail mounting.
  • 2-pole switching. Both poles fused.
  • 3-terminal triac dimmer independently of load current.
  • Build-in current detection to determine if output circuits are OK or not.
  • Lamp circuits galvanic isolated from control circuit
  • Local emergency switches for control of outputs.
  • Connections for main and emergency supply to output circuits.
  • Built-in snubber network which allows termination of a wide range of communication cable, 100-250 Ohm characteristic impedance. End resistors shall not be used.
  • Current detection can be disabled on any circuit if a particular system does not require this feature.
  • The module may also be set locally to manually adjust theoutput voltage.
TRANBERG<sup>® </sup>Relay Output Module for LED Navigation Lights Series TEF4900 R. STAHL

TRANBERG® Fused Relay Output Module with Current Detection Series TEF4900

  • DIN rail mounting.
  • 4 or 8 output circuits.
  • 2-pole switching. Both poles fused.
  • Build-in current detection to determine if output circuits are OK or not.
  • Lamp circuits galvanic isolated from control circuit
  • Local emergency switches for control of outputs.
  • Connections for main and emergency supply to output circuits.
  • Built-in snubber network which allows termination of a wide range of communication cable, 100-250 Ohm characteristic impedance. End resistors shall not be used.
  • Current detection can be disabled on any circuit if a particular system does not require this feature.
TRANBERG<sup>® </sup>Navigation Light System Relay Output Module Series TEF4900 R. STAHL

TRANBERG® Navigation Light System Relay Output Module Series TEF4900

  • DIN rail mounting.
  • 8 individual potential free outputs, 1 C/O contacts.
  • Built-in snubber network which allows termination of a wide range of communication cable, 100-250 Ohm characteristic impedance. End resistors shall not be used.
