NEC/IEC Series 8146/1 Ex e terminal boxes
Art. No.:
278802
Product Type:
8146/1061
Product description:
Ex e terminal box
max. ambient temperature:
+40 °C
min. ambient temperature:
-50 °C
Certificates:
ATEX (PTB), Canada (UL), IECEx (PTB), India (PESO), Korea (KGS), Taiwan (ITRI), USA (UL)
Type of terminals 1:
1 x Phoenix UT
2-conductor, 10 mm2, grey
2-conductor, 10 mm2, grey
Type of terminals PE 1:
1 x Phoenix UT PE
2-conductor, 10 mm², green-yellow
2-conductor, 10 mm², green-yellow
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 8146S |
| Product Type | 8146/1061 |
| Product description | Ex e terminal box |
| Highlights | Versatile Ex e terminal boxes in various sizes and heightsDegree of protection IP66Can be equipped as per customer requirementsEnclosures with captive cover screwsIf required, flanges can be fitted on enclosure sides |
| Functional Description | R. STAHL Series 8146 terminal boxes, made of high-quality, glass fibre reinforced polyester resin, are ideal for use in harsh ambient conditions. With eight basic sizes in various heights, they are universally usable. If requested by the customer, they are equipped with terminal blocks up to 300 mm² and, as an option, a flange can be put on several enclosure sides. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
