8146/1000-C958, Cable end box, Polyester resin, 690 V, 6x 2-conductor, 95 mm2, beige, 2x 2-conductor 95 mm2 beige, Zone 1/2/21/22
- Product Type: 8146/1000-C958
- Art. No.: 136170
On request
Technical data
General
| MY R. STAHL | 8146B |
| Product Type | 8146/1000-C958 |
| Product description | Cable end box |
| Highlights | Cable end boxes for terminals up to 185 mm²Degree of protection IP66Rated operational current depending on enclosure version up to 400 A |
| Functional Description | R. STAHL Series 8146 cable end boxes comprise robust glass fibre reinforced Ex e enclosures. They are equipped with terminals up to 185 mm². These are suitable for voltages up to 690 V, the rated operational current is max. 400 A depending on the enclosure version. The incoming and outgoing leads are fed into the enclosures via cable glands. |
| For customer | BASF |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Cable End Boxes Series 8146 | Data Sheet |
 |
|
| Cable End Boxes Series 8146 | Data Sheet |
 |
|
| Cable end box - 8146/1000-C958 - 136170 - de-DE | Single Data Sheet |
|
|
| Cable end box - 8146/1000-C958 - 136170 - en-GB | Single Data Sheet |
|
|
| Cable end box - 8146/1000-C958 - 136170 - es-ES | Single Data Sheet |
 |
|
| Cable end box - 8146/1000-C958 - 136170 - fr-FR | Single Data Sheet |
 |
