NEC/IEC Series 8150 Ex i terminal boxes
Art. No.:
278814
Product Type:
8150/2-0176-0176-091-3311
Product description:
Ex i terminal box
min. ambient temperature:
-50 °C
max. ambient temperature:
+75 °C
Enclosure material:
Stainless steel 1.4404
Type of terminals 1:
1 x Phoenix UT
2-conductor, 2.5 mm2, blue
2-conductor, 2.5 mm2, blue
Type of terminals 2:
1 x Phoenix UT 2-conductor, 2.5 mm2, grey
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 8150M |
| Product Type | 8150/2-0176-0176-091-3311 |
| Product description | Ex i terminal box |
| Highlights | Version for USA and CanadaResistant Ex i terminal boxes made of stainless steelDegree of protection IP66M8 external earth connectionVersion as screw-on cover or hinged cover with cam locksFittings can be configured individually |
| Functional Description | R. STAHL Series 8150 Ex i terminal boxes are made of brush finished stainless steel (1.4301, AISI 304 or 1.4404, AISI 316L) and are particularly resistant. The optimised design, like the circumferential protection channel on the cover opening and the silicone seal suitable for the most extreme temperature ranges, makes the enclosures usable worldwide. Various optional accessories are available. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Ex i terminal box - 8150/2-0176-0176-091-3311 - 278814 - en-US | Single Data Sheet |
  |
|
| Ex i terminal boxes - 8150/2 - en-US | Product Overview |
|
|
| Ex i terminal box - 8150/2-0176-0176-091-3311 - 278814 - de-DE | Single Data Sheet |
 |
|
| Ex i terminal box - 8150/2-0176-0176-091-3311 - 278814 - en-GB | Single Data Sheet |
 |
|
| Ex i terminal box - 8150/2-0176-0176-091-3311 - 278814 - fr-FR | Single Data Sheet |
 |
|
| Ex i terminal box - 8150/2-0176-0176-091-3311 - 278814 - it-IT | Single Data Sheet |
 |
|
| Ex i terminal box - 8150/2-0176-0176-091-3311 - 278814 - es-ES | Single Data Sheet |
 |
