Compact light fitting Emergency luminaire - 287778

C-LUX compact light fittings Series 6102
Art. No.: 287778

Product Type: 6102/111-0100-150-0111-31-A850-00
max. ambient temperature: +50 °C
min. ambient temperature: -40 °C
Zone Filter: Zone 1 | 2 G | Gb / Zone 2 | 3 G | Gc / Zone 21 | 2 D | Db / Zone 22 | 3 D | Dc
Product status: -Emty-
Certificates: ATEX (IBE), Brazil (ULB), China (NEPSI), IECEx (IBE), Polen (CNBOP)
Luminous flux: 490 lm
Cable glands and entries: 2 x M25 Ø 7 ... 17 mm
Country of origin: DE
More information

Technical data

General

MY R. STAHL 6102A
Product Type 6102/111-0100-150-0111-31-A850-00
Version With deflection optics 0–60°
Variant With deflection optics 0–60°
Highlights Suitable for wall, ceiling and suspended mounting
With either DALI or address module
Emergency exit signs with suspended panel so that they can be read from both sides
Large recognition range d ≥ 30 m
Lightweight, robust and compact design
Functional Description The Series C-LUX 6102 compact light fittings can be used for normal lighting or as emergency luminaires in conjunction with emergency exit signs and/or an address module for use in central battery systems.
Luminous flux 490 lm
Colour temperature 5000 K

Explosion Protection

Electrical Data

Lighting Data

Ambient Conditions

Mechanical Data

Components

Commercial data

Downloads

Description Document Type Language
C-LUX Compact Light Fittings - 6102 - fr-FR Product Overview
pdf
C-LUX Compact Light Fittings - 6102 - es-ES Product Overview
pdf
C-LUX compact light fittings - 6102 - de-DE Product Overview
pdf
C-LUX Compact Light Fittings - 6102 - en-GB Product Overview
pdf
Compact light fitting Emergency luminaire - 6102/111-0100-150-0111-31-A850-00 - 287778 - de-DE Single Data Sheet
pdf
Compact light fitting Emergency luminaire - 6102/111-0100-150-0111-31-A850-00 - 287778 - en-GB Single Data Sheet
pdf
Compact light fitting Emergency luminaire - 6102/111-0100-150-0111-31-A850-00 - 287778 - fr-FR Single Data Sheet
pdf
Compact light fitting Emergency luminaire - 6102/111-0100-150-0111-31-A850-00 - 287778 - es-ES Single Data Sheet
pdf
