8570/21-304-S-51-0-00-XXX, 20 A wall-mounting socket, Polyamide, 100 ... 130 V AC Yellow, 2-pole, 3 conductors, 4 h, NPT 3/4", Polyamide, Zone 1, 2, 21, 22
- Product Type: 8570/21-304-S-51-0-00-XXX
- Art. No.: 290313
On request
Technical data
General
| MY R. STAHL | 8570U |
| Product Type | 8570/21-304-S-51-0-00-XXX |
| Product description | 20 A wall-mounting socket |
| Highlights | Different voltage ranges according to EN 60309Large temperature range of useHigh mechanical impact and shock resistancePerfect protection against penetration of liquids and dusts3D data for download on the websiteAppropriate Series 8570/22 plug |
| Functional Description | R. STAHL Series 8570/21 SolConeX sockets constitute explosion-protected electrical equipment. They are approved for use in hazardous areas that are classified for the division or zone according to NEC 505. The high degree of protection guarantees the highest level of protection against the ingress of dust and/or water in any application position. Self-cleaning lamellar contacts provide optimum contact and the plugs can be inserted and removed in the zero position quickly and easily. The load disconnect switch, with a mechanical locking device and a handle that can be locked in the 0 or I position, is an additional safety feature. |
Explosion Protection
Electrical Data
Device Specific Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Wall-mounting sockets - 8570/21 - de-DE | Product Overview |
 |
|
| Wall-mounting sockets - 8570/21 - en-GB | Product Overview |
 |
|
| Wall-mounting sockets - 8570/21 - en-US | Product Overview |
  |
|
| Wall-mounting sockets - 8570/21 - es-ES | Product Overview |
 |
|
| Wall-mounting sockets - 8570/21 - fr-FR | Product Overview |
 |
|
| 20 A wall-mounting socket - 8570/21-304-S-51-0-00-XXX - 290313 - de-DE | Single Data Sheet |
|
|
| 20 A wall-mounting socket - 8570/21-304-S-51-0-00-XXX - 290313 - en-GB | Single Data Sheet |
|
|
| 20 A wall-mounting socket - 8570/21-304-S-51-0-00-XXX - 290313 - en-US | Single Data Sheet |
|
|
| 20 A wall-mounting socket - 8570/21-304-S-51-0-00-XXX - 290313 - es-ES | Single Data Sheet |
|
|
| 20 A wall-mounting socket - 8570/21-304-S-51-0-00-XXX - 290313 - fr-FR | Single Data Sheet |
|
