Wall-mounting sockets 32 A Series 8571/11
Art. No.:
276193
Product Type:
8571/11-406-S-01-0-00-XXX
Product description:
32 A wall-mounting socket
min. ambient temperature:
-50 °C
Entry 2 type:
8290/3-M32
max. ambient temperature:
+25 °C
Entry 1 type:
8161/7-M32-2109-LT
Rated operational current:
32 A
Certificates:
ATEX (PTB), Brazil (ULB), China (CQST), IECEx (PTB), India (PESO), Korea (KTL), Taiwan (ITRI)
Frequency range:
50 / 60 Hz
Silicone-free:
No
Colour code:
red
Coding (clock hour position):
6
Detailed number of poles:
3 P + PE
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 8571N |
| Product Type | 8571/11-406-S-01-0-00-XXX |
| Highlights | Different voltage ranges according to EN 60309Large temperature range of useHigh mechanical impact and shock resistancePerfect protection against penetration of liquids and dusts3D data for download on the websiteVariants for use in USA/Canada available on request |
| Functional Description |
The R. STAHL 8571/11 series SolConeX sockets for Zone 1/21 in 4- and 5-pole versions have full AC-3 switching capacity up to 32 A. The high degree of protection IP66 ensures maximum protection against the ingress of dust and/or water in any application situation. Self-cleaning lamellar contacts provide optimum contact and the plugs can be inserted and removed in the zero position quickly and easily. The load disconnect switch, with mechanical locking device and a handle that can be locked in the 0 or I position, is an additional safety feature. Further product options available: - Further voltage ranges according to EN 60309 - Silicone-free versions - Ex e or Ex i auxiliary contacts for control and signalling purposes ‒ can also be retrofitted - With NAMUR resistor circuitry - External earth connection - Customer-specific label plates - Plates also in stainless steel - Additional entries ‒ also in metal |
Explosion Protection
Electrical Data
Device Specific Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Wall-mounting sockets - 8571/11 - de-DE | Product Overview |
 |
|
| Wall-mounting Sockets - 8571/11 - en-GB | Product Overview |
 |
|
| Wall-mounting Sockets - 8571/11 - fr-FR | Product Overview |
 |
|
| Wall-mounting Sockets - 8571/11 - es-ES | Product Overview |
 |
|
| 32 A wall-mounting socket - 8571/11-406-S-01-0-00-XXX - 276193 - de-DE | Single Data Sheet |
|
|
| Wall-mounting socket 32 A - 8571/11-406-S-01-0-00-XXX - 276193 - en-GB | Single Data Sheet |
|
|
| Wall-mounting socket 32 A - 8571/11-406-S-01-0-00-XXX - 276193 - fr-FR | Single Data Sheet |
|
|
| Wall-mounting socket 32 A - 8571/11-406-S-01-0-00-XXX - 276193 - es-ES | Single Data Sheet |
|
