TRANBERG® Navigation Lights Controller and Monitoring System Series TEF4800
- Product Type: Controller for TEF 4800 Series
- Art. No.: 332734
On request
Technical data
General
| MY R. STAHL | T4800A |
| Product Type | Controller for TEF 4800 Series |
| Product description | Navigation lights Controller Max 16 Outputs |
| Highlights | Customer specified texts on panel.The system is applicable to both LED and incandescent lamps.Up to 10 pcs. 24 VDC (max. 40 W) incandescent lamps or 16 pcs. LED lamps.Connections for main and emergency supply to output circuits.Can be expanded with a secondary controller. |
| Functional Description |
Control and monitoring system for navigation and signal lights. Delivered for up to 16 output circuits, 24 VDC. TRANBERG® operator panel has a fixed layout of buttons, but allows for customer specified texts. The operator panel has serial communication to the rest of the system. The panel has text in white letters on a black foil, making it easy to read. Applications: Complete control and monitoring of several types of critical lights on vessels: Navigation lights, Signal lights, Suez lights, ROV lights and Towing lights. |
