Linear luminaire with LED EXLUX Series L402/4
Art. No.:
276557
Product Type:
L402/4348-6120-152-1110-11-8400
min. ambient temperature:
-30 °C
Number of lamps:
1
max. ambient temperature:
+45 °C
Frequency range:
50 - 50 Hz
Lamp wattage:
42 W
AC rated operational voltage:
220 - 230 V
Product status:
-Emty-
Lamp:
LED
Light colour:
4000 K – warm neutral white
Degree of protection IP (IEC 60598):
IP66/IP67
Enclosure material:
Polyester resin
Diffuser:
With diffuser
Installed terminal strip:
PE + N- + L+ + N´ + L´
Max. solid connection terminals:
6 mm²
Type of connection cable:
Finely stranded, solid
Disconnection of the luminaire:
No
Through wiring:
with 5 conductors 2.5 mm2
Drilled holes:
3 x M25
Country of origin:
DE
On request
Technical data
General
MY R. STAHL | L402A |
Product Type | L402/4348-6120-152-1110-11-8400 |
Highlights | Highly resistant industrial designLinear luminaire with long-life, efficient LED technology (up to 138 lm/W)Lightweight yet extremely robust, with an impact strength rating of IK10 |
Functional Description | The EXLUX L402/4 luminaire is designed for industrial use and can be fitted to the ceiling, a pole, or alternatively, it can be suspended. A bright light for not much energy is what you get with this efficient LED technology, which offers the added benefit of increased service life – this can be as much as 100,000 hours. The plastic enclosure is easily to open by a central lock. |
Explosion Protection
Electrical Data
Lighting Data
Ambient Conditions
Mechanical Data
Components
Commercial data
Downloads
Description | Document Type | Language | |
---|---|---|---|
Linear luminaire With LED GRP industrial design - L402/4348-6120-152-1110-11-8400 - 276557 - de-DE | Single Data Sheet |
|
|
Linear luminaire With LED GRP industrial design - L402/4348-6120-152-1110-11-8400 - 276557 - en-GB | Single Data Sheet |
|
|
Linear luminaire With LED GRP industrial design - L402/4348-6120-152-1110-11-8400 - 276557 - fr-FR | Single Data Sheet |
|
|
EXLUX Linear Luminaire with LED - L402/4 - es-ES | Product Overview |
|
|
EXLUX linear luminaire with LED - L402/4 - de-DE | Product Overview |
|
|
EXLUX linear luminaire with LED - L402/4 - en-GB | Product Overview |
|
|
EXLUX Linear Luminaire with LED - L402/4 - fr-FR | Product Overview |
|
|
Linear luminaire With LED GRP industrial design - L402/4348-6120-152-1110-11-8400 - 276557 - es-ES | Single Data Sheet |
|
