pac-Bus Series 9194
Art. No.:
160730
Product Type:
9194/50-01
Product description:
pac-Bus terminal set ISpac
Zone Filter:
Zone 2 | 3 G | Gc
Certificates:
ATEX (BVS), Canada (FM), IECEx (BVS), India (PESO), USA (FM)
Connection type:
Screw terminal
Country of origin:
DE
Available in stock
Technical data
General
| MY R. STAHL | 9194A |
| Product variant | Terminal set for pac-Bus |
| Product Type | 9194/50-01 |
| Product description | pac-Bus terminal set ISpac |
| Highlights | Reduced costs thanks to faster wiring of ISpac devicesMounted and snapped onto standard DIN rails – can be extended at any timeSuitable for industrial environments subject to vibration |
| Functional Description | The pac-Bus terminal set allows a direct supply of 24 V DC into a pac-Bus segment consisting of 9194/31-17 and/or 9294/31-12 elements. The set is also necessary for reading out the collective error message of ISpac modules 91xx. |
| Description | For the supply of 24 V DC auxiliary power via terminals (alternative to using the supply module 9193/21-11-11), with jumper for error message chain for ISpac module 91xx |
Explosion Protection
Electrical Data
Auxiliary power
Ambient Conditions
Mechanical Data
Mounting / Installation
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| pac-Bus terminal set ISpac - 9194/50-01 - 160730 - en-US | Single Data Sheet |
  |
|
| pac-Bus terminal set ISpac - 9194/50-01 - 160730 - de-DE | Single Data Sheet |
 |
|
| pac-Bus - 9194 - fr-FR | Product Overview |
 |
|
| pac-Bus - 9194 - es-ES | Product Overview |
 |
|
| pac-Bus - 9194 - de-DE | Product Overview |
|
|
| pac-Bus - 9194 - en-GB | Product Overview |
 |
|
| pac-Bus - 9194 - en-US | Product Overview |
|
|
| pac-Bus terminal set ISpac - 9194/50-01 - 160730 - en-GB | Single Data Sheet |
|
|
| pac-Bus terminal set ISpac - 9194/50-01 - 160730 - fr-FR | Single Data Sheet |
|
|
| pac-Bus terminal set ISpac - 9194/50-01 - 160730 - es-ES | Single Data Sheet |
|
