Socket for CPU & power module Series 9490
Art. No.:
162707
Product Type:
9490/11-12
Product description:
Remote I/O IS1 Socket f. CPU and power module for Zone 1
Zone Filter:
Zone 1 | 2 G | Gb / Zone 2 | 3 G | Gc / Zone 21 | 2 D | Db / Zone 22 | 3 D | Dc
Ex interface zone:
1, 2, 21, 22
Certificates:
ATEX (DEK), ATEX (PTB), Brazil (ULB), Canada (FM), China (NEPSI), IECEx (DEK), IECEx (PTB), Korea (KTL), USA (FM)
Ship approval:
ABS, BVIS, EU RO MR (DNV), KR, LR
Redundancy:
Full redundancy, Line redundancy
Nominal voltage:
24 V DC, 120/230 V AC
Country of origin:
DE
Available in stock
Technical data
General
| MY R. STAHL | 9490A |
| Product variant | Series 9490/11 – socket for CPU & power module |
| Product Type | 9490/11-12 |
| Product description | Remote I/O IS1 Socket f. CPU and power module for Zone 1 |
| Highlights | For simple or redundant installation of the 9440/22 CPM in Zone 1LCD for local display of diagnostics data, input and output valuesPassive design with high availability |
| Functional Description | The 9490 socket is used to install Series 9440/22 IS1+ CPM in Zone 1 and for Ex i fieldbus connection. Single and redundant systems are possible. The socket contains an LCD for assistance during commissioning and troubleshooting to signal level. An innovative mechanism enables the CPM to be connected and disconnected (i.e. hot-swapped) during operation in Zone 1. |
| Description |
Zone 1, connection by means of Ex e terminals, 24 V DC, 120/230 V AC |
Explosion Protection
Safety Data
Electrical Data
Auxiliary power
Galvanic isolation
Device Specific Data
Diagnostics
Ambient Conditions
Mechanical Data
Mounting / Installation
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Remote I/O IS1 Socket f. CPU and power module for Zone 1 - 9490/11-12 - 162707 - de-DE | Single Data Sheet |
 |
|
| Remote I/O IS1 Socket f. CPU and power module for Zone 1 - 9490/11-12 - 162707 - en-GB | Single Data Sheet |
 |
|
| Remote I/O IS1 Socket f. CPU and power module for Zone 1 - 9490/11-12 - 162707 - fr-FR | Single Data Sheet |
 |
|
| Remote I/O IS1 Socket f. CPU and power module for Zone 1 - 9490/11-12 - 162707 - es-ES | Single Data Sheet |
 |
