Digital output module relay for Zone 1/Div. 1 Series 9477/12
Art. No.:
162627
Product Type:
9477/12-08-12
Product description:
Remote I/O IS1 Relay digital output module for Zone 1 Ex d e
Max. power consumption:
4.80 W
Class 1 Division / Zone:
Division 1 / Zone 1
Zone Filter:
Zone 1 | 2 G | Gb / Zone 2 | 3 G | Gc
Ex interface zone:
1, 2
Certificates:
ATEX (PTB), Canada (FM), IECEx (PTB), USA (FM)
Installation:
Zone 1/Division 1
Number of channels:
8 Ex e outputs
Max. switching voltage:
60 V AC
Country of origin:
DE
Available in stock
Technical data
General
| MY R. STAHL | 9477A |
| Product Type | 9477/12-08-12 |
| Product description | Remote I/O IS1 Relay digital output module for Zone 1 Ex d e |
| Highlights | With up to 8 de-energised relay contactsEx e outputs with a high switching capacity up to 100 VAModule hot swap in Zone 1 and Class I, Div. 1 |
| Functional Description | The 9477/12-08-12 digital output module relay for Zone 1 has eight channels for operating non-intrinsically safe solenoid valves with a high switching capacity. De-energised relay contacts (NO contacts) with Ex e or conduit connection technology are available as outputs. Operation in combination with Ex i I/O modules is permissible. |
Explosion Protection
Electrical Data
Auxiliary power
Galvanic isolation
Output
Device Specific Data
Diagnostics
Ambient Conditions
Mechanical Data
Mounting / Installation
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Digital Output Module Relay and Socket for Zone 1 / Div. 1 Series 9477/12 | Data Sheet |
 |
|
| Digital Output Module Relay and Socket for Zone 1 / Div. 1 Series 9477/12 | Data Sheet |
 |
|
| Digital Output Module Relay and Socket for Zone 1 / Div. 1 Series 9477/12 | Data Sheet |
 |
|
| Digital Output Module Relay and Socket for Zone 1 / Div. 1 Series 9477/12 | Data Sheet |
 |
|
| Remote I/O IS1 Relay digital output module for Zone 1 Ex d e - 9477/12-08-12 - 162627 - de-DE | Single Data Sheet |
|
|
| Remote I/O IS1 Relay digital output module for Zone 1 Ex d e - 9477/12-08-12 - 162627 - en-GB | Single Data Sheet |
|
|
| Digital output module relay for Zone 1/Div. 1 - 9477/12 - fr-FR | Product Overview |
|
|
| Digital output module relay for Zone 1/Div. 1 - 9477/12 - es-ES | Product Overview |
|
|
| Digital output module relay for Zone 1/Div. 1 - 9477/12 - de-DE | Product Overview |
|
|
| Digital output module relay for Zone 1/Div. 1 - 9477/12 - en-GB | Product Overview |
|
|
| Digital output module relay for Zone 1/Div. 1 - 9477/12 - en-US | Product Overview |
  |
|
| Remote I/O IS1 Relay digital output module for Zone 1 Ex d e - 9477/12-08-12 - 162627 - fr-FR | Single Data Sheet |
|
|
| Remote I/O IS1 Relay digital output module for Zone 1 Ex d e - 9477/12-08-12 - 162627 - es-ES | Single Data Sheet |
|
