Resistor Series 8453
Art. No.:
145169
Product Type:
8453/1-02-001
Product description:
Control unit With 1 diode Type SB550
max. ambient temperature:
+50 °C
min. ambient temperature:
-60 °C
Zone Filter:
Zone 1 | 2 G | Gb / Zone 2 | 3 G | Gc
Version:
with 1 diodes
Certificates:
ATEX (PTB), Brazil (ULB), IECEx (PTB)
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 8453A |
| Product Type | 8453/1-02-001 |
| Product description | Control unit With 1 diode Type SB550 |
| Version 2 | type SB550 |
| Highlights | Control element for customised equipping with numerous electric and electronic componentsFlameproof enclosure (Ex d) with screw terminals with increased safety (Ex e)Connection cross-section 0.75 to 2.5 mm², solid/finely strandedSimple mounting on mounting rail |
| Functional Description | R. STAHL's 8453 series control units are components with type of protection flameproof enclosure (Ex d) for installation in enclosures with increased safety (Ex e). They contain electronic and electrical components such as resistors, diodes, voltage limiters or fuses. Thanks to their compact design, they are suitable for space-critical applications. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Resistor Series 8453 | Data Sheet |
 |
|
| Resistor Series 8453 | Data Sheet |
 |
|
| Control unit With 1 diode Type SB550 - 8453/1-02-001 - 145169 - de-DE | Single Data Sheet |
|
|
| Control unit With 1 diode Type SB550 - 8453/1-02-001 - 145169 - en-GB | Single Data Sheet |
|
|
| Control unit With 1 diode Type SB550 - 8453/1-02-001 - 145169 - es-ES | Single Data Sheet |
 |
|
| Control unit With 1 diode Type SB550 - 8453/1-02-001 - 145169 - fr-FR | Single Data Sheet |
 |
