C-LUX compact light fittings Series 6102
Art. No.:
287778
Product Type:
6102/111-0100-150-0111-31-A850-00
max. ambient temperature:
+50 °C
min. ambient temperature:
-40 °C
Zone Filter:
Zone 1 | 2 G | Gb / Zone 2 | 3 G | Gc / Zone 21 | 2 D | Db / Zone 22 | 3 D | Dc
Certificates:
ATEX (IBE), Brazil (ULB), China (NEPSI), IECEx (IBE), Polen (CNBOP)
Luminous flux:
490 lm
Cable glands and entries:
2 x M25 Ø 7 … 17 mm
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 6102A |
| Product Type | 6102/111-0100-150-0111-31-A850-00 |
| Version | With deflection optics 0–60° |
| Variant | With deflection optics 0–60° |
| Highlights | Suitable for wall, ceiling and suspended mountingWith either DALI or address moduleEmergency exit signs with suspended panel so that they can be read from both sidesLarge recognition range d ≥ 30 mLightweight, robust and compact design |
| Functional Description | The Series C-LUX 6102 compact light fittings can be used for normal lighting or as emergency luminaires in conjunction with emergency exit signs and/or an address module for use in central battery systems. |
| Luminous flux | 490 lm |
| Colour temperature | 5000 K |
Explosion Protection
Electrical Data
Lighting Data
Ambient Conditions
Mechanical Data
Components
Commercial data
Downloads
