Safety switches Series 8537
Art. No.:
306705
Product Type:
8537/7-712-7000
max. ambient temperature:
+40 °C
min. ambient temperature:
-20 °C
Frequency range:
50 - 60 Hz
AC rated operational voltage:
690 V
Rated operational current:
250 A
Certificates:
ATEX (PTB), China (CQST), IECEx (PTB)
Enclosure material:
Sheet steel, painted
Handle colour:
Black shroud and handle
Detailed number of poles:
3-pole
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 8537A |
| Product Type | 8537/7-712-7000 |
| Highlights | Motor switching capacity AC-3 and AC-23 acc. to IEC 60947-3, EN 60947, DIN VDE 0660 part 107With or without load-shedding contactPositive opening operation of the main contactsIsolating characteristics acc. to DIN VDE 0660Can be locked in the "OFF" position with padlocksRotary actuator with clear switch positionHighly corrosion-resistant external componentsIdentified by a signal orange label "Safety switch" |
| Functional Description | Safety switches ensure that machines and system parts are disconnected from the energy supply during cleaning and repair work as a mandatory requirement. Usual preparatory work such as removal of fuses or disconnection of motors, which can be performed only by electrically skilled persons, is no longer required. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Components
Commercial data
