Commander fused flasher module with current detection
- Product Type: TEF4900935
- Art. No.: 170559
Technical data
General
| MY R. STAHL | T4900I |
| Product Type | TEF4900935 |
| Product description | Commander fused flasher module with current detection |
| Highlights | DIN rail mounting.2-pole switching. Both poles fused.Zero-cross switching.Build-in current detection to determine if output circuits are OK or not.Lamp circuit galvanic isolated from control circuit.Connections for main and emergency supply to output circuit.Build-in snubber network which allows termination of a wide range of communication cable, 100-250 ohm characteristic impedance. End resistors shall not be used.Current detection can be disabled if a particular system does not require this feature. This may be done in software confi guration or as a direct setting on the module.The module may also be set locally to manually adjust fl ashing pattern. |
| Functional Description | Designed for switching and fl ashing of signal lights. Status of light is monitored by a build-in current detector. Delivered for 115/230V lamps.. |
| Description |
TEF4900950 Navigation Control System Old Art. No.: 4900950 |
