Standard enclosure for remote I/O Series 7145
Art. No.:
282643
Product Type:
7145/54-0400-0750-0300
Product description:
IS1 RIO standard encl. Zone 2 With shield bus and power terminals
Width:
400 mm
Height:
750 mm
Designation 2:
With shield bus
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 7145F |
| Product Type | 7145/54-0400-0750-0300 |
| Product description | IS1 RIO standard encl. Zone 2 With shield bus and power terminals |
| Highlights | Short delivery timesCan be used in Zone 2 without acceptance testing or certificationReady for use, prefabricated with entries, BusRails, connection terminals, etc.Modifications, extensions and customer-specific adaptations are possible |
| Functional Description | With the IS1+ standard enclosures for Zone 2, we offer you a variety of prefabricated field enclosures made from 1.4301 stainless steel (V2A). They include all entries, BusRails, cable ducts and connection terminals for auxiliary power.Once the IS1+ components (available separately) have been installed, the enclosures can be used in Zone2 without acceptance testing, and they fulfil the requirements of EN 61439. |
Explosion Protection
Electrical Data
Auxiliary power
Device Specific Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| IS1 RIO standard encl. Zone 2 With shield bus and power terminals - 7145/54-0400-0750-0300 - 282643 ... | Single Data Sheet |
 |
|
| IS1 RIO standard encl. Zone 2 With shield bus and power terminals - 7145/54-0400-0750-0300 - 282643 ... | Single Data Sheet |
 |
|
| Standard enclosure Zone 2 for remote I/O - 7145 - fr-FR | Product Overview |
 |
|
| Standard enclosure Zone 2 for Remote I/O - 7145 - es-ES | Product Overview |
 |
|
| Standard enclosure Zone 2 for Remote I/O - 7145 - de-DE | Product Overview |
|
|
| Standard enclosure Zone 2 for Remote I/O - 7145 - en-GB | Product Overview |
|
|
| Standard enclosure Zone 2 for remote I/O - 7145 - zh-CN | Product Overview |
 |
|
| IS1 RIO standard encl. Zone 2 With shield bus and power terminals - 7145/54-0400-0750-0300 - 282643 ... | Single Data Sheet |
|
|
| IS1 RIO standard encl. Zone 2 With shield bus and power terminals - 7145/54-0400-0750-0300 - 282643 ... | Single Data Sheet |
|
