Relay Series 8510
Art. No.:
217502
Product Type:
8510/111-02-209-020
min. ambient temperature:
-20 °C
max. ambient temperature:
+60 °C
Zone Filter:
M2 | Mb / Zone 1 | 2 G | Gb / Zone 2 | 3 G | Gc
Certificates:
ATEX (BVS), Brazil (ULB), China (CQST), IECEx (BVS)
Rated actuating voltage:
24 V AC
Switching capacity:
2 W
Frequency Hz (for AC):
50, 60
Auxiliary contacts:
2 change-over contact
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 8510A |
| Product Type | 8510/111-02-209-020 |
| Highlights | Type-tested standard componentsCorrosion-resistant enclosure material |
| Functional Description | The R. STAHL Series 8510 relay module provides cost-effective overload protection for motors. It is available in various versions and can contain up to four relays, each with different contact types. It can be screwed into Ex e enclosures so that it is protected against vibrations, while easily accessible connection terminals simplify installation. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Commercial data
