8150/5-V88-28320-3304-3304 PlugSocket, Wall-mntd socket distributor, h, 1 x 8570/28, 20 A, 100 ... 130 V, Yellow, Number of poles on socket 2: 2, Zone 1, 2, 21, 22
- Product Type: 8150/5-V88-28320-3304-3304 PlugSocket
- Art. No.: 254866
Technical data
General
| MY R. STAHL | 8150S |
| Product Type | 8150/5-V88-28320-3304-3304 PlugSocket |
| Highlights | Available with single or duplex sockets, in 20 A or 30 A with a variety of voltages and pin configurationsColour coding and pin configuration makes it physically impossible to mate plugs and sockets of different voltages and current ratings (per IEC 60 309-2)Flush mounting, smooth contours for easy cleaningEnclosure made of 316L brushed stainless steel with concealed gasketInterlocked switch mechanism prevents accidental removal of plug from sockets under load |
| Functional Description | Designed for use in controlled environments; specifically those that are hazardous (classified) locations; these flush-mounted socket distributors support easy cleaning and are free of contaminant holding cavities. Ideal for clean rooms in the pharmaceutical, optical, food, fine chemical and life science industries. The product is quad-certified for use in harsh environments, listed to North American (US and CA) standards, as well as certified for IECEx and ATEX. |
