Sounder, omnidirectional, Ex e, max. 114 dB(A) @ 1 m, Rated operational voltage DC: 133 ... 272 V | 110 ... 240 V, 50 Hz / 60 Hz, Drilled holes: 2 x M20 + 2 x M25, Zone1/2/21/22
- Product Type: YA60/326-PS001-000030-ST000-0000
- Art. No.: 322576
Technical data
General
| MY R. STAHL | YA60C |
| Product Type | YA60/326-PS001-000030-ST000-0000 |
| Highlights | The latest generation of audible and visual alarm devicesEx d/Ex e connection chambersAudible solutions with directional or omnidirectional horn with up to 120 dB(A) at 1 m, 4 tone channels and 64 preconfigured tonesFour output levels can be configuredBrackets and fixings made from stainless steelFastening bracket included |
| Functional Description | The YA60/3 product series provides audible alarm signals which can be used to alert, warn or draw attention to equipment malfunction/start-up or any number of safety-related issues in hazardous areas. The preconfigured signal tones provide a wide range of internationally standardised signal patterns, whereby four channels are available for each, enabling flexible use. |
Explosion Protection
Electrical Data
Acoustic Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| Audible signalling device - YA60/3 - de-DE | Product Overview |
 |
|
| Audible signalling device - YA60/3 - en-GB | Product Overview |
 |
|
| Audible signalling device - YA60/3 - es-ES | Product Overview |
 |
|
| Audible signalling device - YA60/3 - fr-FR | Product Overview |
 |
|
| Audible signalling device Sounder In flameproof enclosure - YA60/326-PS001-000030-ST000-0000 - 32257 ... | Single Data Sheet |
|
|
| Audible signalling device Sounder In flameproof enclosure - YA60/326-PS001-000030-ST000-0000 - 32257 ... | Single Data Sheet |
|
|
| Audible signalling device Sounder In flameproof enclosure - YA60/326-PS001-000030-ST000-0000 - 32257 ... | Single Data Sheet |
|
|
| Audible signalling device Sounder In flameproof enclosure - YA60/326-PS001-000030-ST000-0000 - 32257 ... | Single Data Sheet |
|
