Control device system Series 8040
Art. No.:
223293
Product Type:
8040/1280X-54C01SA70-54C01SA70
max. ambient temperature:
+40 °C
min. ambient temperature:
-60 °C
Top installation position:
Indicator lamp bezel
Installation position: bottom:
Indicator lamp bezel
Certificates:
ATEX (PTB), Canada (UL), China (NEPSI), IECEx (PTB), USA (UL)
Silicone-free:
No
Built-in element top:
LED indicator lamp
Built-in element bottom:
LED indicator lamp
Flange and plates:
Without flange, without plates
Cable glands and entries:
1 x M25 Ø 7 ... 17 mm
Country of origin:
DE
On request
Technical data
General
| MY R. STAHL | 8040B |
| Product variant | LED indicator lamp (2x) |
| Product Type | 8040/1280X-54C01SA70-54C01SA70 |
| Highlights | Flexible: Modular design and three sizes make customer-specific versions possibleLightweight enclosure made of glass fibre reinforced polyester resin (GRP), suitable for the marine industry and offshore applications |
| Functional Description | With the R. STAHL Series 8040 control device system, you can get a clear overview of the control devices. The three combinable sizes and the modular design offer flexibility. You can choose from one standard version and customised variants. |
Explosion Protection
Electrical Data
Ambient Conditions
Mechanical Data
Mounting / Installation
Components
Commercial data
Downloads
| Description | Document Type | Language | |
|---|---|---|---|
| 8040 Note on order number supplement | Data Sheet |
 |
|
| 8040 Note on order number supplement | Data Sheet |
 |
|
| Control device system - 8040 - es-ES | Product Overview |
 |
|
| Control device system - 8040 - de-DE | Product Overview |
|
|
| Control device system - 8040 - en-GB | Product Overview |
|
|
| Control device system - 8040 - fr-FR | Product Overview |
 |
|
| Control device system - 8040 - zh-CN | Product Overview |
 |
|
| Control device system ConSig 8040 series - 8040/1280X-54C01SA70-54C01SA70 - 223293 - de-DE | Single Data Sheet |
|
|
| Control device system ConSig 8040 series - 8040/1280X-54C01SA70-54C01SA70 - 223293 - en-GB | Single Data Sheet |
|
|
| Control device system ConSig 8040 series - 8040/1280X-54C01SA70-54C01SA70 - 223293 - fr-FR | Single Data Sheet |
|
|
| Control device system ConSig 8040 series - 8040/1280X-54C01SA70-54C01SA70 - 223293 - es-ES | Single Data Sheet |
|
